STP. REACTORS

ELECTRO-OXIDATION REACTORS (SYSTEM)
Advanced Oxidation systems for wastewater treatment.

Electrogen Series STP-electro-oxidation reactors - for treatment of industrial wastewater originating from pharma industry, dairy, distillery, textile, dyeing units, meat processing industries& more. Advanced Oxidation systems Oxidates raw sewage and convert industrial/commercial/domestic waste water into clean reusable water or for safe discharge into drain.

domestic-sewage-system

Electrogen Oxidation Reactors helps removal of Organics, Suspended Solids, Turbidity, Algae, Fats & Oil, Grease, Heavy Metals, Odor & Colour and aids in DISINFECTION, DEODORISATION and DECOLORIZATION.

Compact, Modular Electrogen electro-oxidation reactors removes ions, FOG, Silica, Organic particulate matter using electro-oxidation process with functional De-odourization, Decolorization, BOD/COD Removal and disinfects the wastewater finally.
Electrogen Reactors can be supplied as separate units for sewage treatment which are skid-based, controlled by automatic control panel, with Optional PVC/FRP Tanks
Brochure

Specification

1 Mode Of operation Continuous
2 pH range of Sewage/Effluent 4 to 6 (optimum)
3 Operating Temperature 150 ° C to 350 ° C
4 Electrolyzer Orientation Vertical
3 Electrolyzer Tank PVC / FRP

* Contact Manufacturer / dealer for model-specific technical specification.

MODELS

Refer the below table for our Range of Electro-Oxidation Reactor products

Model Design Capacity (litres/hour) Electrolyzer Capacity (KLD)
ELECTROGEN-S-50/1.2 50 1.2
ELECTROGEN-S-100/2.4 100 2.4
ELECTROGEN-S-200/4.8 200 4.8
ELECTROGEN-S-300/7.2 300 7.2
ELECTROGEN-S-425/10 425 10.0
ELECTROGEN-S-625/15 625 15.0
ELECTROGEN-S-850/20 850 20.0
ELECTROGEN-S-1K/25 1050 25.0
ELECTROGEN-S-4.2K/100 4200 100.0
ELECTROGEN-S-21K/500 21000 500.0

Benefits

  • * Non Biological Systems
  • * Start ans Stop At Will
  • * Modular Construction
  • * Continuous/Batch Operation
  • * Easily Expandable
  • * Eco-safe & user Friendly
  • * Color removal
  • * Low operating cost
  • * Requires low power
  • * Low capital cost
  • * Less space required
  • * Consistent & reliable results
  • * Suits for remote locations
  • * Reuse of water for multi application

Applications

Converts Sewage /
Wastewater to Reusable water for

Various Domestic, commercial applications

  • Railways
  • Airports
  • Single-family homes
  • Clustered subdivisions
  • Residential Colonies
  • Municipalities
  • Restaurants
  • Schools
  • Recreational Vehicles
  • Mobile-home parks
  • Office parks
  • Resorts and hotels
  • Golf courses
  • Shopping centers
  • Grocery stores
  • Camps for refugees
  • Military Camps
  • Hospitals & Health Centers
